MACHINERY - SERVICE - REPAIR
MOBILE WASTE COMPACTORS
FOR SKIP LIFT LOADING (GPG PC-XXSL)
USAGE
Enterprises with a large volume of operational waste, such as: supermarkets, shopping centers, hotels, markets, sports and cultural centers, manufacturing enterprises of various types.
LOADING AND TRANSPORTATION
Full compliance with DIN 30720 standard for manufacturing of skip lift containers and using with chain loading trucks.
HIGHLIGHTS
- Tough steel frame and reliable whole-welded body, created for heavy-duty operation with high payloads;
- High compacting capability, up to 6 times reduction of initial volume due to the high compacting pressure up to 324 kPa;
- Reliable, practice-proven press design with a minimum of wearable components;
- High-quality hydraulic unit with a large margin of safety;
- Highly reliable low-voltage automatic and safety control fully meets all CE requirements;
- Simple, intuitive controls that don’t require essential training;
- High-quality polymer coating for high corrosion protection, long-term operation, and excellent appearance.
DESIGNED FOR SUCH TYPES OF WASTE AS
- Cardboard;
- Paper and typographic waste;
- Paper mache and packaging waste;
- Styrofoam and polystyrene foam;
- Metal foil or other easily compressible metal packaging;
- PET bottles and other plastic containers;
- Tin and aluminum cans;
- Other dry, compressed and non-hazardous waste.
MAIN CHARACTERISTICS
- Possibility to integrate press compactors into various production lines due to flexible connection with various tunnels, pipelines, conveyors etc.;
- Possibility to equip the press-compactor with a lifting device for waste containers of different type, reducing labor costs for operation;
- Controller providing an automatic mode of pressing during 3 full cycles with the stop of the plunger in the parking zone, which doesn’t require an additional attention of operator and prevents non-effective using of the hopper chamber space;
- Additional control panel, mounted on the hopper lid for operation from the ramp.
- Possibility to connect additional remote-control unit, which meets EN16486 requirements;
- Fill level sensor, ensuring an automatic detection of 75% and 100% payloads;
- Individual key lock to prevent an unauthorized operation;
- The use of PLC controller provides the possibility of flexible and quick readjustment of press compactor working cycle parameters to meet the specific needs of the customers;
- Climatic design provides outdoor operation in a wide temperature (-20/+45 C) and humidity conditions. Tropical and arctic versions can be supplied upon the special request;
